Genie GTH™-5519

  • Proportional, reversible, continuous auxiliary hydraulic flow
  • Comfortable, spacious cab with tilt steering and ergonomic controls
  • Variable-speed hydrostatic drive
  • Power-assisted steering
  • ROPS/FOPS canopy (ISO compliant), retractable seat belt and illuminated gauge and switch panels
  • Easy-to-use, multifunction joystick control for precise positioning
  • Full-time planetary four-wheel drive and four-wheel steer
  • Two diesel engine options available
  • Manual Genie Quick-Attach™ system for attachments
  • Forward Reach: 11 ft (3.35 m)
  • Lift Capacity: 5,500 lbs (2,500 kg)
  • Lifting Height: 19 ft (5.79 m)
  • Maximum Forward Reach: 11 ft (3.35 m)
  • Maximum Lift Capacity: 5,500 lbs (2,500 kg)
  • Maximum Lift Height: 19 ft (5.79 m)
  • Power Source: Perkins 804D-33 4 cylinder diesel 63 hp (47.0 kW) Deutz D 2011 4 cylinder diesel 68 hp (50.0 kW)
  • Travel Speed: 15 mph (24.1 km/h)
  • Weight*: 9,800 lbs (4,450 kg)

Genie® compact telehandlers

Genie compact telehandlers are the perfect choice for tasks both large and small. Easy to maneuver and convenient to service, with a variety of rugged attachments, Genie compact telehandlers meet the needs of most construction, masonry, landscape and farming applications.

  • Compact footprint and low stowed height — easy to transport and maneuver
  • Three selectable steering modes: front-wheel, coordinated and crab steer
  • Standard auxiliary hydraulic system is easily tailored for a variety of attachments
  • Interchangeable, common components for maintenance efficiency
  • Simple no-tool access to daily inspection points
Equipment Type
Aerial Equipment / Telehandlers
