Fusion Utility Medium Bed
| Key Specifications | |
|---|---|
| Motor | 5kW |
| Controller | 450 Amp Programmable |
| Drivetrain | 16:1 High Speed Rear Axle |
| Speed | 19 mph (30.4 km/h) |
| Battery | 51.2V 105Ah Marxon Lithium-Ion Pack with Heating Module |
| Charger | Onboard – 20 Amp 120V |
| Battery Level Indicator | Digital Touch Screen |
| Chassis | E-Coat and Powder Coated Steel Frame |
| Suspension | Heavy Duty Coil Over Shocks |
| Ground Clearance | 6.5″ (16.5 cm) with Standard Wheels and Tires |
| Brakes | 4 Wheel Premium Hydraulic Disc Brakes |
| Park Brake | Electro Magnetic, Automatically Actuated Once Vehicle is Stopped, Released when Accelerator Pedal is Engaged |
| Wheels and Tires | Black Aluminum, 225/55-12 |
| Range | 37 mi (60km) |
| Turning Radius | 236″ (600 cm) |
| Vehicle Capacity | 4 People |
| Overall Dimensions | 165″ x 48″ x 78″ (420cm x 122cm x 200cm) |
| Utility Bed Dimensions | 59″ x 45″ x 12″ (150cm x 115cm x 31cm) |
| Utility Bed | Aluminum Dump Bed with Electric Hydraulic Actuated Dump |
Details
The Fusion Utility 4 Medium Bed combines comfortable four-passenger capability with hard-working utility with its aluminum dump bed and towing capability. This highly versatile vehicle allows fleets to move the people and gear to the job site in one vehicle or simply allows the option to use it as a people mover in one trip and utility vehicle in the other. Ideal for landscaping, property management, maintenance and tradesmen on job sites, campuses, airports, industrial plants, resorts, zoos and more. Engineered for work, the aluminum bed lifts with the press of a button thanks to its electric hydraulic dump system and the vehicle comes standard with a two-inch receiver for towing. It is also well-equipped with safety and reliability features like three-point seat belts, backup cameras, front brush guards and a full five-year warranty on our maintenance-free lithium-ion battery. The Fusion Utility 4 Medium Bed is the multipurpose tool in your fleet, reliably and efficiently doing the many jobs your operations need done.
- Equipment Type
- Industrial Vehicles and Personnel Carriers / UTVs & LSVs / Utility Vehicles
