Polaris Pro XD Full-Size Diesel Crew


Cylinders Displacement 898 cc
Drive System Type On-Demand 4×4
Engine Type 3-Cylinder Kubota® Diesel
Fuel / Battery System Mechanical Injection
Horsepower / Torque 24.5 HP
Top Speed 26 mph


Bed Box Dimensions (L x W x H) 43.5 x 54 x 11.5 in
Box Capacity 1,250 lb
Estimated Dry Weight 1,878 lb
Fuel Capacity 11.5 gal (43.5 L)
Ground Clearance 11 in
Hitch Towing Rating 2,500 lb
Overall Vehicle Size (L x W x H) 157 x 62.5 x 75 in
Payload Capacity 1950 lbs
Person Capacity 4
Turning Radius (Outer) 207 in (525 cm)
Wheelbase 117 in (297.2 cm)


Front Tires 26 x 10-12 Duro® DI-2042 Power Grip (M/T)
Rear Tires 26 x 10-12 Duro® DI-2042 Power Grip (M/T)


Front/Rear Brakes 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
Parking Brake Park in Transmission + Separate Mechanical Parking Brake Standard


Instrumentation All Digital Gauge, Speedometer, Odometer, Tachometer, 2 Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, Engine Temperature, Hi-Temp Light, Clock, Clutch Belt Slip Warning, Glow Plug Indicator, Low Oil Pressure Indicator, Seat Belt Indicator, Parking Brake Engaged Alarm
Lighting 55W low/ 60W high, LED Tail
Other Standard Features Horn, Backup Alarm, Mechanically Controlled Speed Limiting
Seat Covering Kevlar®-Backed Vinyl (Grey)
Equipment Type
UTVs & LSVs / Industrial Vehicles and Personnel Carriers / Utility Vehicles
