Motrec MX-480 Refuse Hauler
- Passengers: 2
- Loading Capacity: 1000
- Towing Capacity: 6000
- Speed MPH: 10
- Turning Radius: 129
- Accessories: Console on steering column, bolt-on front bumper, DC/DC converter to equalize battery cells, LED charge indicator
- Safety: Deadman seat switch, reverse alarm, horn
- Seats: Two premium seats on slide adjusters
- Steering: Automotive steering wheel
- Suspension: Dual leaf springs on front and rear
- Transmission: Direct drive
- Voltage: 48
- Motor: Brushless AC motor, 15 HP Max (9 HP Continuous)
- Lights: LED dual headlights & tail/brake lights, dual back-up lights
- Indicators: Multifunction display including speedometer, battery state of charge, hour meter, odometer and fault warnings. Password-protected parameters and monitoring capability.
- Battery: Eight 6V-225AH batteries
- Body: All-steel unibody construction. Powder Coating.
- Brakes: Rear hydraulic drum brakes, electromagnetic parking brake with manual hand release, regenerative braking
- Charger: High-frequency (85-265VAC / 45-65Hz, 1kw), built-in and automatic.
- Controller: AC Electronic speed controller
- Drive Axle: Helical gear differential
- Deck Height: 31
- Deck Length: 76
- Deck Width: 45
- Vehicle Height: 45
- Vehicle Length: 126
- Vehicle Width: 45
- Weight: 5250
- Wheel Base: 56
Details
Solve your trash problems and improve maintenance productivity. This zero-noise, zero-emission refuse hauler makes a great choice for shopping malls, campuses, resorts and more. It holds an impressive 2 cubic yards of trash, reducing the number of return trips needed per shift. Optional cab and roll-out battery compartment. A safe, rugged vehicle with unlimited configurations.
- Equipment Type
- Industrial Vehicles and Personnel Carriers / Utility Vehicles
