JLG M400AJP

  • Productivity – work longer with longer duty cycles
  • Environmentally friendly – zero emissions
  • Accessibility – up and over access, optional jib
  • Maneuverability – move over uneven surfaces with Automatic Traction Control
  • Batteries: 8 x 6V, 370 amp-hr
  • Capacity – Hydraulic Reservoir: 4 gal. / 15.14 L
  • Drive Speed – Platform Lowered: 3.20 mph / 5.15 km/h
  • Electrical System: 48 Volts DC
  • Generator / Engine – Brand: Kubota
  • Generator / Engine – Fuel Tank Capacity: 4 gal. / 15.14 L
  • Generator / Engine – Fuel Type: Diesel
  • Generator / Engine – Horsepower / Kilowatts: 7 hp / 5 kW
  • Gradeability – 2WD: 30 %
  • Ground Clearance: 9 in. / 0.22 m
  • Horizontal Jib Rotation: 180 Degrees
  • Horizontal Outreach: 22 ft 5 in. / 6.83 m
  • Jib – Range of articulation: 144 Degrees
  • Machine Height: 6 ft 7 in. / 2.01 m
  • Machine Length: 22 ft / 6.71 m
  • Machine Weight: 14000 lb / 6350.29 kg
  • Machine Width: 5 ft 9 in. / 1.75 m
  • Platform Capacity: 500 lb / 226.80 kg
  • Platform Dimension A: 2 ft 6 in. / 0.76 m
  • Platform Dimension B: 5 ft / 1.52 m
  • Platform Height: 40 ft / 12.19 m
  • Platform Height: 40 ft / 12.19 m
  • Swing: 360 Degrees
  • Swing Type: Non-Continuous
  • Tailswing: Zero
  • Tire Size: 240/55-17.5 Pnuematic
  • Turning Radius – Outside: 10 ft 4 in. / 3.15 m
  • Up and Over Height: 21 ft 6 in. / 6.55 m
  • Wheelbase: 6 ft 7 in. / 2.01 m
Details

Today, more people are demanding environmentally friendly equipment. And more municipalities are requiring “green” building for new construction and renovations. The JLG line of electric boom lifts feature longer run time, greater uptime and higher productivity. These machines are specifically designed so you have fewer scheduled services, a quieter work area, less dependency on hydraulic oils and zero emissions.

Equipment Type
Articulating Boom Lifts / Aerial Equipment
