JLG 450AJ
- More durability and serviceability thanks to the new DuraTough hood design
- Improved multifunction capability increases productivity
- Larger capacity at 550 lb
- Auxiliary Power: 12 Volts DC
- Axle Oscillation: 4 in. / 0.1 m
- Capacity – Fuel Tank: 16 gal. / 60.57 L
- Capacity – Hydraulic Reservoir: 36 gal. / 136.27 L
- Drive Speed – 4WD: 4.25 mph / 6.84 km/h
- Engine Type – Diesel: Deutz D2.9 L4 Tier 4 Final 49 hp
- Engine Type – Dual Fuel: GM Vortec 3000 MPFI 82 hp
- Gradeability – 4WD: 45 %
- Ground Clearance: 1 ft / 0.3 m
- Horizontal Outreach: 25 ft / 7.62 m
- Jib – Range of articulation: 144 Degrees
- Machine Height: 7 ft 5 in. / 2.27 m
- Machine Length: 21 ft 7 in. / 6.58 m
- Machine Weight: 12650 lb / 5737.94 kg
- Machine Width: 7 ft 9 in. / 2.35 m
- Platform Capacity – Unrestricted: 550 lb / 249.48 kg
- Platform Dimension A: 2 ft 6 in. / 0.76 m
- Platform Dimension B: 6 ft / 1.83 m
- Platform Height: 45 ft / 13.72 m
- Platform Height: 45 ft / 13.72 m
- Swing: 355 Degrees
- Swing Type: Non-Continuous
- Tailswing: Zero
- Tire Size: 33/1550 x 16.5 Superwide
- Transport Length: 21 ft 7 in. / 6.58 m
- Turning Radius – Outside: 15 ft 8 in. / 4.78 m
- Up and Over Height: 24 ft / 7.32 m
Details
On the job site, days are measured by productivity. Your productivity. Which means you need equipment that stands up to the day’s demands. JLG® engine powered articulating boom lifts give you the extra reach you need to work over and around obstacles on the job site. They offer exceptional outreach, high capacity, versatile performance and easy maintenance. Larger work envelopes provide you with access to those hard-to-reach places.
- Equipment Type
- Articulating Boom Lifts / Aerial Equipment
