Motrec MT-800 80V

  • Code: MT - 800 - 80V
  • Passengers: 2
  • Loading Capacity: 500
  • Towing Capacity: 50000
  • Speed MPH: 15
  • Speed KPH: 24
  • Turning Radius: 114
  • Standards: Conforms to requirements for type E, UL 583, ANSI B56.9
  • Performance Notes: Specifications and standard equipment are subject to change without notice
  • Drawbar Pull - Normal: 1000
  • Accessories: 80V/12V converter for 12-volt accessories, horn
  • Safety: Deadman seat switch, reverse alarm
  • Seats: Two suspension seats on slide adjusters
  • Steering: Power steering with hydrostatic orbitrol and hydraulic cylinder
  • Suspension: Front leaf spring suspension with dual shock absorbers, rear rubber spring suspension
  • Transmission: Integrated motor/axle, direct drive
  • Voltage: 80
  • Wheels: Solid softy wheels, front 600x9, rear 700x12
  • Motor: 40 hp AC motor
  • Lights: LED dual headlights & tail/brake lights, turn signals
  • Indicators: Digital display, battery status, hour meter, Fault diagnostic
  • Battery: No battery included
  • Body: All-steel unibody construction
  • Brakes: Electric regenerative braking, hydraulic brakes with front dry discs and rear wet discs, hand lever parking brake
  • Charger: No charger included
  • Color: Security orange or federal yellow
  • Controller: Electronic speed controller, Inching controls on rear
  • Drive Axle: Dual planetary wheel drives
  • Battery Height: 31.5
  • Battery Length: 26.8
  • Battery Width: 45.5
  • Vehicle Height: 72
  • Vehicle Length: 107
  • Vehicle Width: 48
  • Wheel Base: 56
  • Weight With Batteries: 8500
  • Battery Weight Max: 4300
  • Battery Weight Min: 4300
  • Weight Without Batteries: 4200
  • Loading Capacity: 500
  • Wheels: Solid softy wheels, front 600x9, rear 700x12

This compact two-seater is engineered for tight industrial settings requiring huge towing power. Its 50,000-lb. payload is backed by a 40 hp AC direct-drive motor with constant laden speed and front suspension with dual shock absorbers. The dual planetary wheel drive with enclosed wet disks reduce maintenance; the electric regenerative brakes lengthen running time. It’s also virtually indestructible, thanks to the one-piece thick plate steel welded chassis reinforced at all high-stress areas.

Equipment Type
Industrial Vehicles and Personnel Carriers / Tugs Trams and Trailers
