Cushman TITAN XD
- Batteries: Eight, 6V Deep Cycle, Swing Out
- Batteries: Eight, 6V Deep Cycle
- Battery Charger: 48-Volt On-Board, Delta Q 120 VAC, UL/CSA
- Battery Charger: 48-Volt On-Board, 120 VAC, UL R/C
- Body and Finish: Diamond Plate. Epoxy Primer + Polyester Topcoat
- Body and Finish: Diamond Plate. Epoxy Primer + Polyester Topcoat
- Cargo Deck Length: 75.0 in (191 cm)
- Cargo Deck Length: 53.5 in (136 cm)
- Cargo Deck Load Capacity: 2600 lb (1179 kg)/ 1600 lb (726 kg) EE
- Cargo Deck Load Capacity: 2200 lb (998kg)/ 1200 lb (544 kg) EE
- Cargo Deck Width: 41.5 in (105 cm)
- Cargo Deck Width: 41.5 in (105 cm)
- Curb Weight: 1752 lb (795 kg)
- Curb Weight: 1720 lb (780 kg)
- Drivetrain: Motor Shaft Direct Drive
- Drivetrain: Motor Shaft Direct Drive
- Dry Weight: 1208 lb (548 kg)
- Dry Weight: 1225 lb (560 kg)
- Electrical System: 48-Volt
- Electrical System: 48-Volt
- Frame: Welded Steel with Powder-Coat
- Frame: Welded Steel with Powder-Coat
- Front and Rear Tires: 5.70 x 8 (Load Range C)
- Front and Rear Tires: 5.70 x 8 (Load Range C)
- Front Suspension: Independent, Transverse Leaf Spring, Shocks
- Front Suspension: Independent, Transverse Leaf Spring, Shocks
- Front Wheel Track: 38.0 in (96 cm)
- Front Wheel Track: 38.0 in (96 cm)
- Gear Selection: Dash-Mounted Forward-Neutral-Reverse
- Gear Selection: Dash-Mounted Forward-Neutral-Reverse
- Ground Clearance: 5.00 in (12 cm)
- Ground Clearance: 5.00 in (12 cm)
- Horsepower: 17.2 hp (12.8 kW) Peak
- Horsepower: 17.2 hp (12.8 kW) (Peak)
- Intersecting Aisle Clearance: 84.0 in (213 cm)
- Intersecting Aisle Clearance: 84.0 in (213 cm)
- Key or Pedal Start: Pedal Start
- Key or Pedal Start: Pedal Start
- Outside Clearance Circle: 21.25 ft (6.47 m)
- Outside Clearance Circle: 21.25 ft (6.47 m)
- Overall Height: 47.5 in (120.6 cm)
- Overall Height: 47.5 in (120.6 cm)
- Overall Height with optional cab: 72.0 in (183 cm)
- Overall Height with optional cab: 72.0 in (183 cm)
- Overall Length: 114.0 in (290 cm)
- Overall Length: 114.0 in (290 cm)
- Overall Width: 44.5 in (113 cm)
- Overall Width: 44.5 in (113 cm)
- Parking Brake: Hand Operated Mechanical
- Parking Brake: Hand Operated Mechanical
- Power Source: 48-Volt DC
- Power Source: 48-Volt DC
- Rear Axle Ratio: 14.9:1
- Rear Axle Ratio: 14.9:1
- Rear Suspension: Leaf Springs & Shock Absorbers
- Rear Suspension: Leaf Springs & Shock Absorbers
- Rear Wheel Track: 38.0 in (96 cm)
- Rear Wheel Track: 38.0 in (96 cm)
- Seating Capacity and Style: 2-person
- Seating Capacity and Style: 4-person
- Service Brake: Front Hydraulic Disc, Rear Hydraulic Drum
- Service Brake: Front Hydraulic Disc, Rear Hydraulic Drum
- Speed (level ground): 14 mph +/- 0.5 mph (21 kph +/- 0.8 kph)
- Speed (level ground): 14 mph +/- 0.5 mph (21 kph +/- 0.8 kph)
- Speed Controller: 400 Amp Solid State, Programmable
- Speed Controller: Solid State 400 Amp Precision Drive System
- Standard Color: Yellow
- Standard Color: Yellow
- Steering: Rack and Pinion
- Steering: Rack and Pinion
- Towing Capacity: 5000 lb (2268 kg)/ 3000 lb (1361 kg) EE
- Towing Capacity: 5000 lb (2268 kg)/ 3000 lb (1361 kg) EE
- Transaxle: Differential with Helical Gears
- Transaxle: Differential with Helical Gears
- Vehicle Load Capacity: 2500 lb (1360 kg)/ 2000 lb (907 kg) EE
- Vehicle Load Capacity: 3000 lb (1361 kg)/ 2000 lb (907 kg) EE
- Wheel Base: 67.0 in (168 cm)
- Wheel Base: 67.0 in (168 cm)
Details
The Titan can carry a ton-
literally.
With its massive payload and big-time
towing capacity, the Titan XD is top dog.
It’s unmatched in power and overall
performance, easily transporting thousands
of pounds of material at once.
- 2- or 4-passenger models
- 21.6-sq-ft, 2,500-lb capacity cargo bed
- 5,000-lb towing capacity
- Equipment Type
- Industrial Vehicles and Personnel Carriers / Burden and Personnel Carriers
